- Grind Number:269QIO8
- Lifter Type: Hydraulic Roller
- Description: HYDRAULIC - Best choice for smaller c.i. applications with very good heads. Extremely wide power rang. 1800+ stall.
- Engine Family: Ford 221-302 C.I. 8 CYL. 1963-1995 (Includes 221, 260, 289 & 302 C.I.)
- Cam Family: 4-PATTERN O.E. Hydraulic Roller Camshafts
Specifications:
- RPM Range: 1700 to 6300
- Valve Timing: .006
- Lobe Separation: 108.5 / 107.5°
- Intake Centerline: 105 / 104°
- Intake
- Valve Lash: Hyd.
- Duration: 271 / 269
- Duration @ .050" Lift: 219 / 217
- Valve Lift: .603 / .600
- Lobe Lift: .399 / .399
- Exhaust
- Valve Lash: Hyd.
- Duration: 283 / 281
- Duration @ .050" Lift: 229 / 227
- Valve Lift: .590 / .587
- Lobe Lift: .389 / .389
