The Visconti Tuning NexGen Flex Fuel Kit for the Toyota GR Corolla provides a fully CAN bus integrated ethanol content monitoring system designed to communicate directly with the factory ECU.
The Visconti Tuning GR Corolla & Yaris Flex Fuel Kit is the most advanced and user-friendly flex fuel solution available. This fully CAN bus-integrated system communicates directly with the factory ECU while keeping all OEM sensors and fuel lines intact.
CANBOX is our Bluetooth BLE Ethanol Content Analyzer that provides core flex fuel functionality. It supports both iOS and Android applications for configuration, over-the-air updates, and advanced diagnostics.
CANBOXPRO adds four configurable I/O channels. These support 0–5 volt sensor inputs for features such as fuel pressure or coolant pressure monitoring, as well as PWM outputs for triggering relays or controlling auxiliary systems such as nitrous or meth. CANBOXPRO allows additional inputs to be added now or expanded later as your setup evolves.
What’s included with the kit:
- Visconti Ethanol Content Analyzer
- Genuine GM Continental Ethanol Content Sensor
- Visconti Custom 180 degree quick connect fuel fittings.
- Visconti Plug & Play Wiring Harness
ATTENTION TUNERS:
Our CANBOX integrates natively with EcuTek RaceROM and requires no custom CAN setup. There is no need to define CAN IDs, data bytes, update rates, or emulate third-party devices. Our hardware is EcuTek CX29 certified and uses EcuTek’s current CAN bus protocol for direct ECU communication.
Technical details and development history:
We were the first to develop a flex fuel kit that communicated directly with the factory ECU on a vehicle that did not originally include that functionality, originally developed on the Nissan GTR.
The ethanol content sensor connected by the firewall using our custom fuel fittings, allowing you to keep your factory fuel lines.
We take pride in knowing the name of every individual involved in producing this kit, which is proudly designed and manufactured in the USA. The harnesses are handmade with automotive-grade TXL XLPE insulated wire and assembled in an ISO Certified Facility.
