| TARGET HP (HP) | 580 | |
| BEARING TYPE | Ball Bearing | |
| INITIAL BOOST SETTING (kgf/cm2) | 1 | |
| COMPRESSOR WHEEL | TURBINE WHEEL | |
| ⒶIND(mm) | 50.3 | 56 |
| ⒷEXD(mm) | 68 | 47.5 |
| Trim | 55 | 72 |
| Blades | 6/6 | 9 |
| Material | A2618 | K418 |
| Production | CNC BILLET | CAST |
| COMPRESSOR HOUSING | TURBINE HOUSING | |
| IND(mm) | 51..3 | T25 |
| EXD(mm) | 38.75 | RB26DETT |
| A/R | 0.74 | 0.73 |
*** B/B TURBOCHARGER KIT ARMS BX8260 RB26DETT - TB403A-NS05B
| TARGET HP (HP) | 650 | |
| BEARING TYPE | Ball Bearing | |
| INITIAL BOOST SETTING (kgf/cm2) | 1 | |
| COMPRESSOR WHEEL | TURBINE WHEEL | |
| ⒶIND(mm) | 52.6 | 67 |
| ⒷEXD(mm) | 68 | 58.8 |
| Trim | 60 | 77 |
| Blades | 6/6 | 9 |
| Material | A2618 | K418 |
| Production | CNC BILLET | CAST |
| COMPRESSOR HOUSING | TURBINE HOUSING | |
| IND(mm) | 53.5 | T25 |
| EXD(mm) | 38.75 | RB26DETT |
| A/R | 0.74 | 0.73 |
